Application Limits
- Suction head up to 9m
- Liquid temperature up to +40℃
- Ambient temperature up to +40℃
- Max. Working pressure: 6bar
- Voltage fluctuation should not exceed 10% of rated value.
- pH: 6.5 to 8.5
Features
- Complete models
- Copper impeller, stainless steel pump cover
- Pump body with installation foot set
Motor
- Single-Phase 220V/50Hz
- Motor: 2 pole asynchronous motor, copper wires, built-in thermal protector, fully closed fan cooling, continuous running
- Protection: IP44
- Insulation: Class B
Optional Available On Request
- 304 stainless steel welding shaft
- Electrophoretic pump body and connections
- NSK bearing
- Motor whose insulation class is F
- Other voltage or frequency is 60Hz
Parameter Table
| MODEL | POWER | VOLTAGE | MAX.FLOW | MAX.HEAD | INLET/OUTLET | GW | |
| KW | HP | （V） | （m3/h) | (m) | mm | (Kg) | |
| JET60 | 0.37 | 0.5 | 220V,50Hz | 2.5 | 32 | 25 | 9.5 |
| JET80 | 0.55 | 0.75 | 220V,50Hz | 3 | 41 | 25 | 17 |
| JET100 | 0.75 | 1 | 220V,50Hz | 3.5 | 46 | 25 | 18 |
| JET150 | 1.1 | 1.5 | 220V,50Hz | 4 | 50 | 25 | 18.5 |
