Application Limits
◎Suction head: up to 8m
◎Liquid temperature: up to +40℃
◎Ambient temperature: up to +40℃
◎Max. Working pressure: 6bar
◎pH: 6.5 to 8.5
Parameter Table
| MODEL | POWER | VOLTAGE | MAX.FLOW | MAX.HEAD | MAX.SUCT | INLET/OUTLET | GW | PACKING DIMENSION | |
| KW | HP | （V） | (L/min) | (m) | (m) | mm(in) | (Kg) | (cm) | |
| QB60 | 0.37 | 0.50 | 220V,50Hz | 26.7 | 33 | 8 | 25（1″） | 5.1 | 25*11.5*15 |
| QB70 | 0.55 | 0.74 | 220V,50Hz | 40 | 48 | 8 | 25（1″） | 9.1 | 30*14.5*18 |
| QB80 | 0.75 | 1.01 | 220V,50Hz | 45 | 50 | 8 | 25（1″） | 9.3 | 30*14.5*18 |
