Mechanical Pressure Controller JSK-9
Mechanical Pressure Controller JSK-9 - 图片 2
Mechanical Pressure Controller JSK-9 - 图片 3
Mechanical Pressure Controller JSK-9 - 图片 4

Mechanical Pressure Controller JSK-9

& Free Shipping

JSK-9 mechanical type water pump pressure switch totally automatic control according to the pressure setting. Used for double spring to adjust cut in & cut out pressure. It is suitable for single phase 110V-240V and three phases 400V water pumps.



send inquiry
分类： ,

Common Specifications

Material: Metal, Plastic

Max. current: 16(8)A

Min. cut-in: 15PSI

Max. cut-out: 100PSI

Flange: Steel

Cover color: Black

Pressure switch differential: 20 to 30PSI

Protection rating: IP44

Max. working temperature: 55 deg C

Features

– Pressure Switch Application: water pumps

– Made of high quality materials for strong strength and long durability

– When the system pipeline pressure reaches the upper limit, the power supply is automatically cut off and the pump stops working.

– When the system pressure reaches the lower limit, the power supply is automatically switched on and the pump starts to work.

– Suitable for water pumps, such as self-priming water pump, injection water pump, garden water pump, etc.


Specifications And Dimensions

Model: JSK-9(female)

Box size (cm): 10.5×6.7×10.5

Carton size (cm): 54×34×23

QTY/CTN: 50PCS

N.W (kg): 19

G.W (kg): 21

Model: JSK-9(male)

Box size (cm): 10.5×6.7×12.5

Carton size (cm): 54×26.5×35

QTY/CTN: 50PCS

N.W (kg): 19.5

G.W (kg): 22
